Boats, Electric Wheelchairs, Solar Energy Storage Systems, Golf Carts, Electric Power Systems, Electric Bicycles,UPS,power Tools,military Equipment,aerospace

Operating Temperature(℃):

-20-60

Cathode Materials:

LiFePO4

Capacity:

12.8V 100Ah

Charge Voltage:

14.4±0.1V

Discharge Voltage:

10.0V

Charge Current:

50A

Cycle Life:

≥1500times 0.5C(80%DOD)

Internal Resistance:

≤60mΩ

Battery Cell:

LiFePO4

Warranty:

3 Years

Highlight:

12V 100AH Lithium Ion Battery Pack

Lithium Ion Battery Pack BMS

Lifepo4 1000 Cycles THLB Battery

Product Description

12V 100AH Lithium Ion Battery Pack with BMS

This high-performance 12V 100AH Lithium Ion Battery Pack features LiFePO4 chemistry with an internal resistance below 60 milliohms and delivers up to 1000+ cycles. As a direct manufacturer, we provide reliable power solutions with comprehensive BMS protection.

Customization Note: The following parameters are presented as reference examples. We specialize in designing, developing, and producing fully customized battery solutions tailored to your specific requirements.

Product Gallery

Technical Specifications

Normal Voltage	12.8V
Rated Capacity	100±3Ah (0.2C)
Energy	Approximately 1290Wh
Cycle Life	≥1500 cycles at 0.5C (80% DOD)
Charge Voltage	14.4±0.1V
Charge Current	50A
Max. Charge Current	100A
Charge Temperature	0℃ to 45℃
Discharge Temperature	-20℃ to 60℃
Storage Temperature	0℃ to 40℃
Material System	LiFePO4
Material of Case	ABS
Dimensions	(330±1)mm × (172±1)mm × (215±2)mm
Weight	12.7±0.3Kg
Terminal	M8
Passive Protection Functions	Over charge protection, Over discharge protection, Temperature protection, Balanced function

LiFePO4 Battery Features

Reliable Quality: Comprehensive quality control from material selection through battery cell production to final assembly ensures full product traceability
Long Cycle Life: Up to 10 times longer cycle life than lead acid batteries, minimizing replacement costs and reducing total cost of ownership
Higher Power: Delivers twice the power of lead acid batteries with higher discharge rates and supports faster charging with higher charge currents
Lighter Weight: Approximately 50% lighter than comparable lead acid batteries with wider operating temperature range (-20℃ to 60℃)
Enhanced Safety: Eliminates risk of explosion or combustion due to high impact, overcharging, or short circuit situations
Environmentally Friendly: Contains no poisonous or harmful substances in production or use, widely accepted globally

Packaging & Delivery

Manufacturer Profile

Frequently Asked Questions

Q1: Are you a factory or a trading company?

A1: We are a professional rechargeable lithium-ion battery and LiFePO4 battery manufacturer located in Shandong, certified with ISO9001:2008 quality system.

Q2: Can I have samples to test? And what is lead time for sample order?

A2: Yes, we can supply samples with a lead time of 7-10 days. Buyer pays for sample cost and shipping cost.

Q3: Do you provide after-sales service?

A3: Yes, we offer a 3-year warranty. If any quality problems occur on our side during this period, we will send a replacement.

Q4: What is your company's advantage?

A4: We supply only high-quality lithium batteries, guarantee on-time shipment, and provide excellent after-sales service.

Q5: Do you accept OEM/ODM?

A5: Yes, OEM/ODM services are available.

Q6: What information do you need to make a customized battery pack?

A6: We need: 1. Battery pack dimensions (mm), 2. Capacity, 3. Voltage, 4. Max discharge current, 5. Cable and connector types, 6. Casing and terminals if required, 7. Any protection circuits needed.

Q7: Are your batteries real capacity?

A7: All our battery cells are Grade A, 100% new with real capacity.

Q8: What kind of certificates do you have?

A8: We can provide CE, ROHS, FCC, IEC62133, MSDS, UN38.3 certifications.

Q9: What is your lead time for mass production?

A9: Typically 25-30 days depending on the item after receiving down payment and sample confirmation.
