1024Wh LFP12V Rechargeable Battery Pack 12.8V 7.5Ah To 30Ah 18650 Lithium Ion Batteries
| Place of Origin | China |
|---|---|
| Brand Name | THLB |
| Model Number | 12.8v |
| Minimum Order Quantity | 500 units |
| Price | $28/units 500-9999 units |
| Packaging Details | Standard Packaging |
| Delivery Time | 7-15 Working Days |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Max Load Quantity(cells) | 4 | Cycle Life | 1000 Cycles |
|---|---|---|---|
| Application | Boats, Electric Wheelchairs, Solar Energy Storage Systems | Operating Temperature(℃) | -20-60 |
| Cathode Materials | LiFePO4 | Chargeable | Yes |
| Anode Material | LFP | The Charging Ratio | 0.5C |
| The Discharge Rate | 1C | Storage Type | 0-60℃ |
| Electric Energy | 102.4 | Voltage | 12V 12.8V |
| OEM/ODM | Accepatable | ||
| Highlight | LFP12V Rechargeable Battery Pack,1024Wh Rechargeable Battery Pack,30Ah 18650 Lithium Ion Batteries |
||
Product Description
1024Wh LFP12V Rechargeable Battery Pack
12.8V 7.5Ah to 30Ah 18650 LiFePO4 Cylindrical Lithium Ion Batteries
Technical Specifications
| Nominal Voltage | 12.8V |
| Typical Capacity | 8Ah |
| Discharge Normal Current | <8A |
| Discharge Cut-off Voltage | 10V |
| Charging Voltage | 14.4V |
| Charging Current | 4A |
| Charging Method | CC/CV |
| Cut-off Current | 0.01C |
| Discharging Inner Resistance | <=70mΩ |
| Charge Temperature Range | 0℃～+45℃ |
| Discharge Temperature Range | -20℃～+60℃ |
| Storage Temperature Range | 0℃～+40℃ (capacity 80%) |
| Protection Functions | Overcharge protection, over discharge protection, temperature protection, balanced function |
| Battery Case Material | ABS shell |
| Dimensions | (152±1)mm × (65±1)mm × (95±1)mm |
| Cycle Life | 1500 cycles (capacity retention rate >80%) |
Packaging & Delivery
To better ensure the safety of your goods, we provide professional, environmentally friendly, convenient and efficient packaging services.
Company Profile
Frequently Asked Questions
Are you a factory or a trading company?
We are a professional rechargeable lithium-ion battery and LiFePO4 battery manufacturer located in Shandong. We passed ISO9001:2008 quality system certification.
Can I have samples to test? And what is lead time for sample order?
Yes, we can supply samples. The lead time for samples is 7-10 days, and buyer pays for sample cost and shipping cost.
Do you provide after-sales service?
Yes, the warranty is 3 years. If any quality problems occur on our side during this period, we can send new ones as replacement.
What is your company's advantage?
We only supply high level quality lithium batteries and we guarantee on-time shipment. We also provide excellent after-sales service.
Do you accept OEM/ODM?
Yes, it is available.
What information do you need to make a customized battery pack?
We need the details below:
- Size of the battery pack you need in mm
- Capacity of the Battery pack
- Voltage of the battery pack
- Max discharge current
- Cable and connector types you need
- Casing and Terminals if required
- Any protection circuits you may need
Are your batteries real capacity?
All of our battery cells are Grade A, 100% new and real capacity.
What kind of certificates do you have?
We can provide CE, ROHS, FCC, IEC62133, MSDS, UN38.3.
What is your lead time for the mass production?
Generally speaking, about 25-30 days depending on different items after getting down payment and confirmation about the samples.
