Rechargeable THLB Battery 12.8V 7.5AH 8AH 12AH Lifepo4 Battery Pack
| Place of Origin | China |
|---|---|
| Brand Name | THLB |
| Model Number | 12.8v 7.5ah |
| Minimum Order Quantity | 10 pieces |
| Price | $23/pieces 10-49 pieces |
| Packaging Details | Standard Packaging |
| Delivery Time | 7-15 Working Days |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Max Load Quantity(cells) | 4 | Cycle Life | 1000 Cycles |
|---|---|---|---|
| Application | Consumer Electronics, Boats, Solar Energy Storage Systems, Electric Wheelchairs, Golf Carts | Operating Temperature(℃) | -20-60 |
| Cathode Materials | LiFePO4 | Type | Li-ion |
| Voltage | 12.8V | Capacity | 7.5Ah |
| Category | Rechargeable Batteries Pack | Cell Configuration | LiFePO4 18650 3.2V 1600mAh-4S5P |
| Cycle Characteristic | 2000 Times | Working Temperature | -20°C~60°C |
| Battery Weight | 1.1±0.1kg | Reference Battery Size | 151.5*65*95 Mm |
| Color | Black | ||
| Highlight | Rechargeable THLB Battery,THLB Battery 12.8V 7.5AH,12AH Lifepo4 Battery Pack |
||
Product Description
Rechargeable THLB Battery 12.8V 7.5AH 8AH 12AH Lifepo4 Battery Pack
High-capacity rechargeable 12.8V LiFePO4 lithium ion battery pack with extended cycle life and professional-grade performance characteristics.
Package Contents
| Item | Quantity |
|---|---|
| 12.8V 7.5Ah LiFePO4 Battery Module | 1 |
| PCM (Protection Circuit Module) | 1 |
| Plastic Battery Case | 1 |
| T1 Terminals | 2 |
Product Specifications
| Normal Voltage | 12.8V |
| Normal Capacity | 7.5Ah |
| Battery Energy | 96Wh |
| Inner Resistance | < 90mΩ |
| Battery Cycle Life | 2000 Times @100%DOD 6000 Times @80%DOD |
| Cell Configuration | LiFePO4 18650 3.2V 1600mAh-4S5P |
| Reference Battery Size | (151.5±1)*(65±1)*(95±1) mm |
| Reference Battery Weight | 1.1±0.1 kg |
| Battery Encapsulation | Plastic Case |
| Charge Voltage | 14.4V |
| Charge Mode | CC/CV |
| Normal Charge Current | 1.5A |
| Normal Discharge Current | 4A |
| Max. Continuous Output Current | 7.5A |
| Max. Continuous Output Power | 96W |
| Passive Protection Function | Over charge protection; Over discharge protection; Over current protection, etc |
| Operation Temperature Range | Charge: 0°C - 45°C Discharge: -20°C - 60°C |
| Battery Storage Temperature | -20°C - 25°C |
| Individual Cell Approval | CE / RoHS / UN38.3 / UL 1642 / IEC 62133 / CB / KC / BIS |
Safety Performance Classification
- Resistance to heavy loads - tested according to regulations, no ignition or explosion
- Resistance to thermal shock - tested according to regulations, no ignition or explosion
- Anti-overcharge - tested according to regulations, no ignition or explosion
- Resistance to overdischarge - tested according to regulations, no ignition or explosion
- Resistance to short circuit - tested according to regulations, no ignition or explosion
- High temperature storage - tested according to regulations, no leakage, smoke, fire or explosion
- Anti-heating - tested according to regulations, no battery penetration through screen
- Anti-puncture - tested according to regulations, no ignition or explosion
- Anti-extrusion - tested according to regulations, no ignition or explosion
- Resistance to low pressure - tested according to regulations, no leakage, smoke, fire or explosion
- Constant damp heat - tested according to regulations, no deformation, rust, smoke or explosion
- Anti-vibration - tested according to regulations, no damage, leakage, smoke or explosion
- Anti-collision - tested according to regulations, no damage, leakage, smoke or explosion
- Temperature cycling - tested according to regulations, no leakage, smoke, ignition or explosion
- Flame retardant properties - meets GB/T2408-2008 FH-1 and FV-0 requirements
- Insulation resistance - metal case insulation resistance not less than 2 MΩ
Our Company
Packing & Delivery
Frequently Asked Questions
Q1. Can I have few free samples for evaluation?
A: Yes, free samples are available, but shipping costs are not covered.
Q2. What about the lead time?
A: Samples require 3-5 days. Mass production time is approximately 2-3 weeks.
Q3. Do you have any MOQ limit for bulk order?
A: Minimum order quantity is 100 pieces.
Q4. How do you ship the goods and how long does it take to arrive?
A: Samples and small trial orders: Courier shipping with door-to-door delivery (6-10 days). Bulk orders: Air or sea shipping.
Q5. How to proceed an order for Lithium ion cell?
A: Confirm cell models of interest, receive specifications and quotation, confirm order quantity, issue purchase order, and production begins after deposit or full payment confirmation.
Q6. Is it OK to print my logo on lithium ion cell product?
A: Yes, OEM services are welcomed.
Q7: Do you offer guarantee for the products?
A: Yes, 3-5 Years Warranty included.
