THLB Lithium Iron Phosphate Battery 1200 Cycles LFP Prismatic Solar Energy Battery

Place of Origin	China
Brand Name	THLB
Model Number	12V150Ah
Minimum Order Quantity	10 pieces
Price	$298/pieces 10-49 pieces
Packaging Details	Standard Packaging
Delivery Time	7-15 Working Days

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details

Max Load Quantity(cells)	4	Cycle Life	1200 Cycles
Application	Boats, Electric Wheelchairs, Solar Energy Storage Systems, Golf Carts	Operating Temperature(℃)	-20-60
Cathode Materials	LiFePO4	Type	Li-ion
Voltage	12V	Capacity	150Ah
Category	Rechargeable Batteries Pack	Cell Configuration	LiFePO4 26650 3.2V 3200mAh-4S47P
Cycle Characteristic	2000 Times	Working Temperature	-20°C~60°C
Battery Weight	18.2±0.2 Kg	Reference Battery Size	(342±1)(173±1)(212±1) Mm
Color	White,black
Highlight	THLB Lithium Iron Phosphate Battery , 1200 Cycles LFP Prismatic , LFP Prismatic Solar Energy Battery

Leave a Message

Product Description

THLB Lithium Iron Phosphate Battery 1200 Cycles LFP Prismatic Solar Energy Battery

18.2 Kilogram Lithium Iron Phosphate Battery Pack 12V 150Ah LFP Prismatic Solar Energy Cell with rated cycle life of 1200 cycles

Main Kit Includes

1 x 12V150Ah LiFePO4 Battery Module

1 x 4S-150A PCM

1 x Plastic Battery Case

2 x M8 Terminals

Product Specification - Lithium Iron Phosphate Battery Pack 12V 150Ah for Camp Car

Normal Voltage	12.8V
Normal Capacity	150Ah
Battery Energy	1920Wh
Inner Resistance	< 60mΩ
Battery Cycle Life	2000 Times @100%DOD 6000 Times @80%DOD
Cell Configuration	LiFePO4 26650 3.2V 3200mAh-4S47P
Reference Battery Size	(342±1)(173±1)(212±1) mm
Reference Battery Weight	18.2±0.2 kg
Battery Encapsulation	Plastic Case
Charge Voltage	14.4V
Charge Mode	CC/CV
Normal Charge Current	<=50A
Normal Discharge Current	75A
Max. Continuous Output Current	150A
Max. Continuous Output Power	1920W
Passive Protection Function	Over charge protection; Over discharge protection; Over current protection, etc
Operation Temperature Range	Charge: 0°C---45°C Discharge: -20°C---60°C
Battery Storage Temperature	-20°C---25°C
Individual Cell Approval	CE / RoHS / UN38.3 / UL 1642 / IEC 62133 / CB / KC / BIS

Our Company

Packing & Delivery

Frequently Asked Questions

Q1. Can I have few free samples for evaluation?

A: Yes, free samples are ok, but not covering shipping cost

Q2. What about the lead time?

A: Samples needs 3-5 days
B: Mass production time is approx 2-3 weeks

Q3. Do you have any MOQ limit for bulk order?

A: MOQ=100pcs

Q4. How do you ship the goods and how long does it take to arrive?

A: Samples and small quantity trial order: Courier shipping with door to door; normally 6-10 days
B: Big quantity bulk order: Air shipping or Sea shipping

Q5. How to proceed an order for Lithium ion cell?

A: Pls confirm the cell models that you are interested in
B: We send cell specifications and best quotation to you for reference
C: You confirm the quotation and inform quantity or issue PO, we will send PI accordingly
D: After deposit or full payment confirmed, production started

Q6. Is it OK to print my logo on lithium ion cell product?

A: Yes. OEM is welcomed

Q7: Do you offer guarantee for the products?

A: Yes, 3-5 Years Warranty
