LiFePO4 THLB Battery 12.8V 16Ah Lithium Battery Pack For Golf Cart

Brand Name:	THLB
Model Number:	12.8V16Ah LiFePO4 Battery
MOQ:	10 pieces
Price:	$64/pieces 10-99 pieces
Packaging Details:	Standard Packaging

Detail Information

Product Description

Detail Information

Place of Origin:

China

Max Load Quantity(cells):

Cycle Life:

800 Cycles

Application:

Boats, Power Tools, Toys, Electric Wheelchairs, Golf Carts, Electric Power Systems, Electric Bicycles/Scooters

Operating Temperature(℃):

-20-60

Cathode Materials:

LiFePO4

Type:

LiFePO4

Voltage:

12.8V

Capacity:

Category:

Rechargeable Batteries Pack

Cell Configuration:

LiFePO4 26650 3.2V 3200mAh-4S5P

Cycle Characteristic:

1500-2000 Times

Working Temperature:

-20°C~60°C

Battery Weight:

2.2±0.2 Kg

Color:

Black

Highlight:

12.8V 16Ah Lithium Battery Pack

Lithium Battery Pack For Golf Cart

LiFePO4 THLB Battery 12.8V

Product Description

LiFePO4 THLB Battery 12.8V 16Ah Lithium Battery Pack For Golf Cart

LiFePO4 Cathode Materials 2.2 Kilogram 12.8V 16Ah Lithium Ion Battery Pack with 800 cycles, specifically designed for golf trolley operation.

Main Kit Includes

1x 12.8V16Ah LiFePO4 Battery Module

1x 4S-30A PCM

1x Standard Golf Trolley ABS Battery Case

1x T-bar + Anderson Connector

Product Specification

Nominal voltage	12.8V
Normal Capacity	16±0.5Ah (At 0.2C discharge rate)
Max discharge continuous current	≤25A
Discharge cut-off voltage	About 10V
Charge voltage	14.4±0.15V
Charge current	≤3A
Charge mode	CC/CV, please use special lithium charger
Discharging Inner resistance	≤70mΩ
Charge temperature	0℃～+45℃
Discharge temperature	When environment temperature is higher than 45℃, please ensure proper ventilation and heat dissipation
Operating humidity	RH≤85%, protect when humidity exceeds 85%
Storage temperature	0℃～40℃ (Capacity 80%), recommended long-term storage: 15~25℃
Storage humidity	RH≤50%, ensure sealed protection for oxidizable components
Protection functions	Over charge protection, Over discharge protection, Temperature protection, Balanced function
Shell material	ABS
Weight	2.2±0.1kg
Size (LWH)	(168±1)mm × (128±1)mm × (75±2)mm
Cycle life	800 cycles (capacity retention rate ≥80%) with standard charge/discharge at 0.2C rate
Individual Cell Approvals	CE / RoHS / UN38.3 / UL 1642 / IEC 62133 / CB / KC / BIS
