LiFePO4 Battery Cell 2.5A 12V Replacement Lead Acid Battery 7ah 9ah 10ah 12ah 14ah 15ah
| Place of Origin | China |
|---|---|
| Brand Name | THLB |
| Model Number | 12.8V12Ah |
| Minimum Order Quantity | 5 watts |
| Price | $29/watts 5-99 watts |
| Packaging Details | Standard Packaging |
| Delivery Time | 7-15 Working Days |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Features | High Energy Density,Long Cycle Life Etc | Max Load Quantity(cells) | 4 |
|---|---|---|---|
| Cycle Life | 1200 Cycles | Application | Electric Wheelchairs, Electric Bicycles/Scooters, Robot Vacuum Cleaner |
| Operating Temperature(℃) | -20-60 | Cathode Materials | LiFePO4 |
| Battery Type | Lead Acid Replacement Battery | Capacity | 12.8V 12Ah |
| Charge Voltage | 14.4V | Discharge Voltage | 10.0V |
| Current | 2.5A | Cycle Life | 3000 Times |
| Battery Cell | LiFePO4 | Warranty | 3 Years |
| Highlight | LiFePO4 Battery Cell 2.5A 12V,Replacement Lead Acid Battery 7ah,Replacement Lead Acid Battery 9ah |
||
Product Description
LiFePO4 Battery Cell 2.5A 12V Replacement Lead Acid Battery
Factory direct wholesale 12V lithium batteries available in 7Ah, 9Ah, 10Ah, 12Ah, 14Ah, 15Ah, 20Ah, 24Ah, 40Ah, 50Ah, and 60Ah capacities. Perfect replacement for lead acid batteries with superior performance and longevity.
Customization Available: All parameters shown are for reference only. We can design, develop, and produce fully customized battery solutions according to your specific requirements.
Technical Specifications
| Parameter | Value |
|---|---|
| Normal Voltage | 12.8V |
| Rated Capacity | 12.8±0.5Ah (0.2C) |
| Energy | About 163.8Wh |
| Cycle Life | ≥2,000@0.2C (100% DOD) ≥6,000@0.2C (80% DOD) ≥10,000@0.2C (50% DOD) |
| Charge Voltage | 14.4±0.15V |
| Charge Current | 2.5A |
| Max. Charge Current | 6A |
| Discharge Cut-Off Voltage | About 10V |
| Charge Temperature | 0℃ to 45℃ |
| Discharge Temperature | -20℃ to 60℃ |
| Storage Temperature | 0℃ to 40℃ |
| Material System | LiFePO4 |
| Material of Case | Plastic |
| Dimensions (mm) | (151.5±1)mm × (99.4±1)mm × (95±2)mm |
| Weight | 1.7±0.1Kg |
| Terminal | T2 |
| Passive Protection Function | Over charge protection, Over discharge protection, Temperature protection, Balanced function |
LiFePO4 Battery Features
- Reliable Quality: Comprehensive quality control from material selection to battery assembly ensures full product traceability and consistent performance.
- Long Cycle Life: Up to 10 times longer cycle life than lead acid batteries, reducing replacement costs and total cost of ownership.
- Higher Power: Delivers twice the power of lead acid batteries with higher discharge rates and faster charging capabilities.
- Lighter Weight: Approximately 50% lighter than comparable lead acid batteries with wider operating temperature range (-20℃ to 60℃).
- Enhanced Safety: Eliminates risk of explosion or combustion due to high impact, overcharging, or short circuit situations.
- Environmentally Friendly: Contains no poisonous or harmful substances, widely accepted globally for eco-friendly applications.
Additional Products
Packing & Delivery
Company Profile
Frequently Asked Questions
Q1: Are you a factory or a trading company?
A1: We are a professional rechargeable lithium-ion battery and LiFePO4 battery manufacturer located in Shandong, certified with ISO9001:2008 quality system.
Q2: Can I have samples to test? And what is lead time for sample order?
A2: Yes, we can supply samples with a lead time of 7-10 days. Buyer pays for sample cost and shipping cost.
Q3: Do you provide after-sales service?
A3: Yes, we offer a 3-year warranty. If any quality problems occur on our side during this period, we will send a new replacement.
Q4: What is your company's advantage?
A4: We supply only high-quality lithium batteries, guarantee on-time shipment, and provide excellent after-sales service.
Q5: Do you accept OEM/ODM?
A5: Yes, OEM and ODM services are available.
Q6: What information do you need to make a customized battery pack?
A6: We need: 1. Battery pack dimensions in mm, 2. Capacity, 3. Voltage, 4. Max discharge current, 5. Cable and connector types, 6. Casing and terminals if required, 7. Any protection circuits needed.
Q7: Are your batteries real capacity?
A7: All our battery cells are Grade A, 100% new with real capacity as specified.
Q8: What kind of certificates do you have?
A8: We can provide CE, ROHS, FCC, IEC62133, MSDS, UN38.3 certifications.
Q9: What is your lead time for mass production?
A9: Typically 25-30 days depending on the item after receiving down payment and sample confirmation.
