LiMn2O4 48v Electric Bicycle Battery 800 To 1000 Times OEM ODM

Place of Origin	China
Brand Name	THLB
Model Number	48v25ah
Minimum Order Quantity	10 pieces
Price	$147/pieces 10-499 pieces
Packaging Details	Standard Packaging
Delivery Time	7-15 Working Days

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details

Max Load Quantity(cells)	4	Cycle Life	1000 Cycles
Application	Electric Wheelchairs, Golf Carts, Electric Bicycles/Scooters, E-Bike, Electric Bicycle, Electric Bike	Operating Temperature(℃)	-20-60
Cathode Materials	LiMn2O4	Cycle Life	800-1000 Times
Battery Type	Lithium Battery	Warranty	3 Year
Nominal Capacity (Ah)	12ah/16ah/25ah/30ah/48ah/60ah	Weight	Approx 3.5kg
Shell Material	Plastic	OEM/ODM	Available
Voltage	24ah 20/36/48v
Highlight	LiMn2O4 48v Electric Bicycle Battery , 1000 Times ebike rechargeable battery , OEM ODM Electric Bicycle Battery

Leave a Message

Product Description

LiMn2O4 48V Electric Bicycle Battery

Approximately 3.5kg rechargeable lithium iron phosphate battery pack with 25Ah capacity, available in 20V, 36V, and 48V configurations. Features an exceptional cycle life of 800 to 1000 charge cycles.

Product Overview

THLB enterprise specializes in research, design, manufacturing, sales, and service of lithium-ion batteries, power batteries, battery packs, and BMS battery management systems. Our products are widely used in:

Intelligent manufacturing
New energy automotive power batteries
Automotive starting power supply
Communication base station backup power supply
Electric bicycles
Wind and solar energy storage systems
Home energy storage battery solutions

THLB has implemented leading R&D systems and test equipment, establishing comprehensive process flows and strict quality management systems. Our advanced automated lithium battery production lines and PACK automatic production lines ensure high safety, reliability, and stability for all products.

Cell Specifications

Item	Specifications	Note
Capacity	Nominal capacity: 4000 mAh Minimum Capacity: 3900 mAh	0.5C
Alternating Internal Resistance	Max: 18mΩ	AC 1 kHZ
Nominal Voltage	3.2 V
Charging Voltage	3.65±0.05 V
Standard Charge Conditions	Current: 0.5C (2000 mA) Voltage: 3.65V Cut-off Current: 80±5mA	25°C±2°C 0.02C
Max Charging Current	0°C≤T≤5°C: 0.2C (800 mA) 5°C≤T≤15°C: 0.5C (2000mA) 15°C≤T≤55°C: 1C (4000 mA)
Standard Discharge Conditions	Current: 0.5C (2000 mA) Cut-off Voltage: 2.0±0.05V	25°C±2°C
Max. Continuous Discharge Current	-20°C≤T≤5°C: 0.5C (2000 mA) 5°C≤T≤45°C: 2C (8000mA) 45°C≤T≤75°C: 1C (4000 mA)
Max. Pulse Discharge Current	15A (5s)
Working Temperature	Charge: 0～55°C Discharge: -20~75°C
Storage Temperature	1 month: -20~60°C 3 months: -20~40°C 12 months: -20~20°C
Weight	≤90g
Dimension	Height: 65.2±0.3mm Diameter: 26.2±0.2mm	Figure 1
Appearance	No rupture, no scratch, no deformation, no stain, no electrolyte leakage, etc.
